Product Description
- Wood screws are designed with aggressive threads for grabbing and holding the wood material.
- Wood screws over an inch long have a threadless shank, typically one-third the overall length.
- Type 17 point screws feature a long sharp point that is fluted in order to capture chips.
- Diameter (Nominal): #6
- Thread Pitch: 13
- Diameter (Dimension): 0.1406"
- Length (Nominal): 1-1/2"
- Product Class: Externally Threaded Fasteners
- Order: Thread Cutting Fasteners
- Category: Wood Screws
- System of Measurement: US Units
- Brand: Aspen Fasteners®
- Head Style: Flat Countersunk Head
- Head Style Detail: 82 Degree Countersink, Nibs Under Head
- Drive Style: Cruciform Recess Drive
- Drive Detail: Phillips Type H
- Threading: Deep Thread
- Thread Length: 2/3rd Thread Length
- Thread Direction: Right-Hand Thread
- Point: Type 17 Point
- Material: Steel
- Material Grade: AISI-SAE C1022 Steel
- Material Processes: Case Hardened
- Coating: Zinc Plated and Baked
- Coating Color: Clear
- Coating Standard: 1,000 Hour Salt Spray Rated
- Hardness Rating: Vickers HV 500 minimum
- NB: Product images are copyrighted artistic representations which may not reflect the product's exact appearance, proportions and/or relative dimensions.
Product Videos
Custom Field
Drive Style Cruciform Recess Drive
Coating Process Zinc Plated and Baked, Clear
Material AISI-SAE C1022 Steel
Length 1-1/2"
Head Style Flat Countersunk Head
Category Wood Screws
System of Measurement US Units
Diameter/Pitch #6-13
