Product Description
- Also known as thread forming screws, thread rolling screws, trilob screws, or trilobe screws.
- An internal hex socket drive is also known as an Allen drive.
- Diameter (Nominal): M8
- Diameter (Dimension): 8mm
- Thread Pitch: 1.25
- Length (Nominal): 40mm
- Thread Length (Minimum): 40mm
- Recess Size: 6mm
- Head Diameter: 13mm
- Head Height, Overall: 8mm
- Product Class: Externally Threaded Fasteners
- Order: Thread Cutting Fasteners
- Category: Thread Rolling Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Form and Design: Trilobe Triangular Body with Threads for Metals
- Head Style: Cylindrical Head
- Drive Style: Hex Socket Drive
- Threading: Machine Screw Threading
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Steel
- Material Grade: AISI-SAE C1022 Steel
- Material Processes: Case Hardened
- Coating: Zinc Plated and Waxed
- Coating Color: Clear
- Hardness Rating: Vickers HV 450
- Standards and Specifications: DIN 7500 Type E
- NB: Product images are copyrighted artistic representations which may not reflect the product's exact appearance, proportions and/or relative dimensions.
Product Videos
Custom Field
System of Measurement Metric
Material AISI-SAE C1022 Steel
Diameter/Pitch M8-1.25
Drive Style Hex Socket Drive
Length 40mm
Coating Process Zinc Plated and Waxed, Clear
Category Thread Rolling Screws
Standards and Specifications DIN 7500 Type E
Head Style Cylindrical Head
