Product Description
- Serrated washers are made with small sharp serrations that, when compressed, prevent loosening.
- Effective as a lock washer when used with harder materials.
- Diameter (Nominal): M5
- Diameter (Dimension): 5mm
- Inside Diameter (Nominal): 5.3mm
- Outside Diameter (Nominal): 10mm
- Thickness (Nominal): 0.6mm
- Product Class: Washers
- Order: Lock Washers
- Category: Serrated Lock Washers
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Form and Design: Countersunk External Type "V"
- Material: Steel
- Material Grade: Spring Steel
- Coating: Zinc Plated
- Coating Color: Clear
- Standards and Specifications: DIN 6798 Type V
- A note on our product images: The copyrighted images are schematic representations. These are artistic renderings which may not reflect the exact appearance, proportions and/or relative dimensions of the actual products. For more precise imagery and/or technical references, please contact our customer support team.
Product Videos
Custom Field
Material Spring Steel
Category Serrated Lock Washers
Coating Process Zinc Plated, Clear
Thickness 0.6mm
System of Measurement Metric
Standards and Specifications DIN 6798 Type V
Inner Diameter 5.3mm
Diameter/Pitch M5
Outer Diameter 10mm
