Product Description
- Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
- Pan head screws are also known as raised cheese head screws.
- A Pozidriv recess allows for increased torque while reducing the risk of drive cam-out.
- Class 4.8 steel is a low or medium carbon steel with a minimum tensile strength of 420N/mm-2 (Mpa).
- Diameter (Nominal): M5
- Diameter (Dimension): 5mm
- Thread Pitch: 0.8
- Length (Nominal): 70mm
- Thread Length (Minimum): 70mm
- Recess Size: #2
- Head Diameter: 10mm
- Head Height, Overall: 3.95mm
- Product Class: Externally Threaded Fasteners
- Order: Machine Thread Fasteners
- Category: Machine Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Head Style: Pan Head
- Drive Style: Cruciform Recess Drive
- Drive Detail: Pozidriv Type Z
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Steel
- Material Grade: Class 4.8 Steel
- Coating: Zinc Plated
- Coating Color: Clear
- Standards and Specifications: DIN 7985A / ISO 7045
- NB: Product images are copyrighted artistic representations which may not reflect the product's exact appearance, proportions and/or relative dimensions.
Product Videos
Custom Field
Category Machine Screws
Drive Style Cruciform Recess Drive
Head Style Pan Head
Coating Process Zinc Plated, Clear
System of Measurement Metric
Standards and Specifications DIN 7985A / ISO 7045
Diameter/Pitch M5-0.8
Material Class 4.8 Steel
Length 70mm
