Product Description
- Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
- A Pozidriv recess allows for increased torque while reducing the risk of drive cam-out.
- Class 4.8 steel is a low or medium carbon steel with a minimum tensile strength of 420N/mm-2 (Mpa).
- Diameter (Nominal): M4
- Diameter (Dimension): 4mm
- Thread Pitch: 0.7
- Length (Nominal): 30mm
- Thread Length (Minimum): 27.8mm
- Recess Size: #2
- Head Diameter: 7.5mm
- Head Height, Overall: 2.2mm
- Product Class: Externally Threaded Fasteners
- Order: Machine Thread Fasteners
- Category: Machine Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Head Style: Flat Countersunk Head
- Head Style Detail: 90 Degree Countersink
- Drive Style: Cruciform Recess Drive
- Drive Detail: Pozidriv Type Z
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Steel
- Material Grade: Class 4.8 Steel
- Coating: Zinc Plated
- Coating Color: Clear
- Standards and Specifications: DIN 965 / ISO 7046
- NB: Product images are copyrighted artistic representations which may not reflect the product's exact appearance, proportions and/or relative dimensions.
Product Videos
Custom Field
Length 30mm
Material Class 4.8 Steel
Category Machine Screws
System of Measurement Metric
Standards and Specifications DIN 965 / ISO 7046
Head Style Flat Countersunk Head
Diameter/Pitch M4-0.7
Drive Style Cruciform Recess Drive
Coating Process Zinc Plated, Clear
