Product Description
- DIN 125 / ISO 7089 are standard commercial metric flat washers.
- A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- The nominal diameter is the bolt size to use for this flat washer.
- Diameter (Nominal): M39
- Diameter (Dimension): 39mm
- Inside Diameter (Nominal): 40mm
- Inside Diameter (Minimum): 40mm
- Inside Diameter (Maximum): 40.62mm
- Outside Diameter (Nominal): 72mm
- Outside Diameter (Minimum): 70.8mm
- Outside Diameter (Maximum): 72mm
- Thickness (Nominal): 6mm
- Thickness (Minimum): 5.4mm
- Thickness (Maximum): 6.6mm
- Category: Standard Flat Washers
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Form and Design: Not Chamfered
- Material: Stainless Steel
- Material Grade: A2 Stainless Steel
- Coating: Uncoated
- Origin: Origin Undefined
- Standards and Specifications: DIN 125 Type A / ISO 7089
Product Videos
Custom Field
Brand Aspen Fasteners
Category Standard Flat Washers
Coating Uncoated
Diameter (Dimension) 39mm
Diameter (Nominal) M39
Form and Design Not Chamfered
Inside Diameter (Maximum) 40.62mm
Inside Diameter (Minimum) 40mm
Inside Diameter (Nominal) 40mm
Material Stainless Steel
Material Grade A2 Stainless Steel
Order Flat Washers
Origin Origin Undefined
Outside Diameter (Maximum) 72mm
Outside Diameter (Minimum) 70.8mm
Outside Diameter (Nominal) 72mm
POS ME057-39X40X72X6-000050
Product Class Washers
Standards and Specifications DIN 125 Type A / ISO 7089
System of Measurement Metric
Thickness (Maximum) 6.6mm
Thickness (Minimum) 5.4mm
Thickness (Nominal) 6mm
