Product Description
- Serrated washers are made with small sharp serrations that, when compressed, prevent loosening.
- Effective as a lock washer when used with harder materials.
- A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Diameter (Nominal): M2
- Diameter (Dimension): 2mm
- Inside Diameter (Nominal): 2.2mm
- Outside Diameter (Nominal): 4.5mm
- Thickness (Nominal): 0.3mm
- Product Class: Washers
- Order: Lock Washers
- Category: Serrated Lock Washers
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Form and Design: Internal Type "J"
- Material: Stainless Steel
- Material Grade: A2 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: DIN 6798 Type J
- NB: Product images are copyrighted artistic representations which may not reflect the product's exact appearance, proportions and/or relative dimensions.
Product Videos
Custom Field
Material A2 Stainless Steel
Inner Diameter 2.2mm
Coating Process Uncoated
Thickness 0.3mm
Outer Diameter 4.5mm
Category Serrated Lock Washers
Standards and Specifications DIN 6798 Type J
System of Measurement Metric
Diameter/Pitch M2
