Product Description
- Nuts with a domed end on one side are also known as crown nuts, blind nuts, cap nuts or dome nuts.
- Machined from a single piece of metal.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Diameter (Nominal): M18
- Diameter (Dimension): 18mm
- Thread Pitch: 2.5
- Thread Length (Minimum): 15mm
- Outside Diameter (Nominal): 26mm
- Across Flats (Basic): 27mm
- Height (Basic): 32mm
- Product Class: Internally Threaded Fasteners
- Order: Nuts
- Category: Acorn Cap Dome Nuts
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Form and Design: High Type
- Drive Style: External Hex Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: AISI 303 Stainless Steel (18-8)
- Material Processes: Machined
- Coating: Uncoated
- Standards and Specifications: DIN 1587
- NB: Product images are copyrighted artistic representations which may not reflect the product's exact appearance, proportions and/or relative dimensions.
Product Videos
Custom Field
System of Measurement Metric
Outer Diameter 26mm
Drive Style External Hex Drive
Standards and Specifications DIN 1587
Material AISI 303 Stainless Steel (18-8)
Category Acorn Cap Dome Nuts
Coating Process Uncoated
Diameter/Pitch M18-2.5
