Product Description
- Hex cap screws are manufactured to tighter tolerances as compared to hex bolts.
- Class 10.9 steel is an alloy steel, quenched and tempered, with a minimum tensile strength of 1,040/mm-2 (Mpa).
- The washer face under the head provides a precision bearing surface.
- The chamfered point improves engagement with a nut or pre-tapped hole.
- Diameter (Nominal): M16
- Thread Pitch: 2.0
- Diameter (Dimension): 16mm
- Length (Nominal): 60mm
- Thread Length (Nominal): 60mm
- Across Flats (Basic): 24mm
- Across Flats (Minimum): 23.67mm
- Across Flats (Maximum): 24mm
- Head Height, Overall: 10mm
- Head Height, Overall (Minimum): 9.82mm
- Head Height, Overall (Maximum): 10.18mm
- Category: Cap Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Head Style: Hex Head
- Head Style Detail: Washer Face
- Drive Style: External Hex Drive
- Pitch: Coarse Thread
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Point: Chamfered Point
- Material: Steel
- Material Grade: Class 10.9 Steel
- Material Processes: Quenched and Tempered
- Coating: Uncoated
- Origin: Origin Undefined
- Standards and Specifications: DIN 933 / ISO 4017
Product Videos
Custom Field
Across Flats (Basic) 24mm
Across Flats (Maximum) 24mm
Across Flats (Minimum) 23.67mm
Brand Aspen Fasteners
Category Cap Screws
Coating Uncoated
Diameter (Dimension) 16mm
Diameter (Nominal) M16
Drive Style External Hex Drive
Head Height, Overall 10mm
Head Height, Overall (Maximum) 10.18mm
Head Height, Overall (Minimum) 9.82mm
Head Style Hex Head
Head Style Detail Washer Face
Length (Nominal) 60mm
Material Steel
Material Grade Class 10.9 Steel
Material Processes Quenched and Tempered
Order Machine Thread Fasteners
Origin Origin Undefined
POS ME003-1620X60-00030
Pitch Coarse Thread
Point Chamfered Point
Product Class Externally Threaded Fasteners
Standards and Specifications DIN 933 / ISO 4017
System of Measurement Metric
Thread Direction Right-Hand Thread
Thread Length Full Thread
Thread Length (Nominal) 60mm
Thread Pitch 2.0
