Product Description
- Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
- A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Diameter (Nominal): M12
- Thread Pitch: 1.75
- Diameter (Dimension): 12mm
- Length (Nominal): 20mm
- Thread Length (Minimum): 20mm
- Recess Size: 8mm
- Head Diameter: 21mm
- Head Height, Overall: 6.6mm
- Product Class: Externally Threaded Fasteners
- Order: Machine Thread Fasteners
- Category: Machine Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Head Style: Button Head
- Drive Style: Tamper-Resistant Hex Socket Pin Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: A2 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: Art. 9111
- NB: Product images are copyrighted artistic representations which may not reflect the product's exact appearance, proportions and/or relative dimensions.
Product Videos
Custom Field
Category Machine Screws
Standards and Specifications Art. 9111
Coating Process Uncoated
Drive Style Tamper-Resistant Hex Socket Pin Drive
Material A2 Stainless Steel
Length 20mm
Head Style Button Head
System of Measurement Metric
Diameter/Pitch M12-1.75
