Product Description
- Regular square nuts are chamfered on the top side.
- Diameter (Nominal): 1"
- Thread Pitch: 8
- Diameter (Dimension): 1"
- Thread Length (Nominal): 0.875"
- Across Flats (Basic): 1-1/2"
- Across Flats (Minimum): 1.45"
- Across Flats (Maximum): 1.5"
- Height (Basic): 7/8"
- Height (Minimum): 0.847"
- Height (Maximum): 0.903"
- Category: Square Regular Nuts
- System of Measurement: Inch
- Brand: Aspen Fasteners
- Drive Style: External Square Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Steel
- Coating: Zinc Plated
- Coating Color: Clear
- Origin: Origin Undefined
- Standards and Specifications: ASME B18.2.2 and SAE J995
Product Videos
Custom Field
Across Flats (Basic) 1-1/2"
Across Flats (Maximum) 1.5"
Across Flats (Minimum) 1.45"
Brand Aspen Fasteners
Category Square Regular Nuts
Coating Zinc Plated
Coating Color Clear
Diameter (Dimension) 1"
Diameter (Nominal) 1"
Drive Style External Square Drive
Height (Basic) 7/8"
Height (Maximum) 0.903"
Height (Minimum) 0.847"
Material Steel
Order Nuts
Origin Origin Undefined
POS NU097-18-000100,NU097-18-000050,NU097-18-000130
Product Class Internally Threaded Fasteners
Standards and Specifications ASME B18.2.2 and SAE J995
System of Measurement Inch
Thread Direction Right-Hand Thread
Thread Length Full Thread
Thread Length (Nominal) 0.875"
Thread Pitch 8
