Product Description
- Flange on the nut acts like a washer to increase the bearing surface and distribute the load.
- Also known as elastic stop nuts, this self locking nut uses a nylon collar that resists turning.
- Type 304 stainless steel is defined as a Chromium-Nickel austenitic alloy.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Diameter (Nominal): 1/4"
- Diameter (Dimension): 0.25"
- Thread Pitch: 20
- Thread Length: 0.3"
- Across Flats (Basic): 0.438"
- Height (Basic): 0.3"
- Flange Diameter: 0.56"
- Product Class: Internally Threaded Fasteners
- Order: Lock Nuts
- Category: Hex Nylon Insert Flange Stop Lock Nuts
- System of Measurement: US Units
- Brand: Aspen Fasteners®
- Drive Style: External Hex Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: AISI 304 Stainless Steel (18-8)
- Coating: Uncoated
- A note on our product images: The copyrighted images are schematic representations. These are artistic renderings which may not reflect the exact appearance, proportions and/or relative dimensions of the actual products. For more precise imagery and/or technical references, please contact our customer support team.
Product Videos
Custom Field
Material AISI 304 Stainless Steel (18-8)
Coating Process Uncoated
Diameter/Pitch 1/4"-20
System of Measurement US Units
Drive Style External Hex Drive
Category Hex Nylon Insert Flange Stop Lock Nuts
